Pioneer Agricultural, Connect Under Pressure Quick Couplers, Breakaway Sleeve (ISO 5675) - 8200 Series
8200 Series Couplers_SKU_5
Information
| Afdeling | Quick Coupling Division |
| Applikation | Hydraulic |
| Body materiale | Steel |
| Body størrelse | 1/2 inch |
| Brand | Pioneer |
| Fittingforbindelsestype | Pipe Thread |
| Flowhastighed | 12 Gal/min |
| Forbindelsestype | NPSF, ORB |
| Gevindstørrelse | Female |
| Koblingshalvdel | Coupler |
| Konstruktionsmaterialer | Steel |
| Låstype | locking balls |
| Maks. driftstemperatur | 250 �F |
| Maks. driftstryk | 300 psi + psi |
| Medie | Hydraulic Fluids |
| Mindste driftstemperatur | -40 �F |
| Muffetype | Push-pull breakaway |
| Overfladebehandlingstype | Zinc with clear trivalent chromate |
| Pakningsmateriale | Nitrile |
| partId (right) | 2673155 |
| Specifikationer overholdt | ISO 5675 |
| Teknologi | Fluid and Gas Handling |
| Tilslutningsgevindstørrelse (tomme) | 26x1,5 |
| Udvekslingstype | Pioneer |
| Ventiltype | Connect under pressure poppet |
